ISO 9001:2015 CERTIFIED

API 5L GR. B / L245 SEAMLESS & WELDED LINE
PIPE SUPPLIER

Multi Metals (India) specializes in API 5L GR. B PSL1 & PSL2 Pipes certified and tested in accordance with ISO 3183, ISO 15156, NACE MRO175 / 103, HIC, SWC, SSC, SSCC, SOUR SERVICE, H2 SERVICE, IMPACT, POST WELD HEAT TREATMENT (PWHT), IBR, HIGH YIELD, IPS-M-PI-190, IPS-M-PI-221 ETC.

Multi Metals (India) is India's largest exporter of GR. B or L245 PSL1/PSL2 (N, M, Q, R) Line Pipe We Supply GR. B / L245 Steel Line Pipe in Diameter 1/2” to 100” & Pipe wall thickness Schedule 10, SCH 40/ 80 & SCH 160. We Stock API 5L GR. B material in Seamless and Welded (ERW, HFW, LSAW) in both PSL1 & PSL2 We solicit contacts from reputed Pipe mills to represent them & stock their products for resale to EPC Companies / Promoting Companies.

High Yield API 5L GR. B / L245 Seamless & Welded Carbon Steel Pipe Manufacturer

Stockist, Exporter of API 5L GR. B / L245 Seamless & Welded Line Pipe – PSL1 & PSL2

API 5L Grade GR. B / L245 ERW & LSAW Pipe FOR SALE AT BEST PRICE IN INDIA

Table of Contents :-

API 5L GR. B / L245 Line Pipe Specification :-

API 5L GR. B Pipe also called L245 pipe (by ISO 3183), named by minimum yield strength 245 Mpa. It’s a most common grade in API 5L and it requires large quantities in most of pipelines for oil and gas transmissions. API 5L GR. B Pipes are produced into seamless pipe and welded steel pipe with Spiral Submerged Arc Welding Pipe (SSAW), Longitudinal Seam Submerged Arc Welding Pipe (LSAW), Electric Resistance Welding (ERW)

API 5L GR. B / L245 Line Pipes ranges in PSL1, PSL2, onshore/offshore, and sour service.
API 5L GR. B PSL1 is for common use material delivery conditions R as Rolled.
API 5L GR. B PSL2 is strict and higher than PSL1 on chemicals, mechanical properties and test requirements.
PSL2 specified with suffix letter N, Q, M, eg API 5L GR. BQ/M/N (Where sour services is described as API 5L GR. BQS/MS)

Suffix Letter Means :-

R: As rolled
N: Normalizing rolled, Normalized formed, Normalized
Q: Quenched & Tempered
M: Thermomechanical rolled or Thermomechanical formed
S: Sour Service Use

View here differences between PSL1 and PSL2.
View API 5L Pipe Specification (46th Edition Updated on 2020)

SUPPLY RANGE :-

API 5L GR. B Pipe Standard	:	API 5L GR. B (Q, M, N, QS, MS), ISO 3183 L245 (API specification 5L - 46th Edition, November 1, 2018)
API 5L GR. B Pipe Product Specification Level	:	PSL1, PSL2, NACE, Sour Service, HIC, SSC, H2 Service
API 5L GR. B Pipe Types	:	Seamless and Welded in ERW, LSAW, DSAW, SSAW (HSAW) .
API 5L GR. B Pipe OD Range (Seamless)	:	1/2” – 30” (21.3 mm – 762 mm)
API 5L GR. B Pipe OD Range (ERW)	:	1/2” – 20” (21.3mm – 508mm)
API 5L GR. B Pipe OD Range (LSAW/DSAW)	:	16” – 100” (406mm – 2500MM)
API 5L GR. B Pipe OD Range (SSAW/HSAW)	:	up to 100” (2500mm)
API 5L GR. B Pipe Wall Thickness / Schedule	:	SCH-20, SCH-40, SCH-STD, SCH-XS, SCH-80, SCH-100, SCH-120, SCH-160, SCH-XXS, HEAVY THICKNESS
API 5L GR. B Pipe Pipe Length	:	SRL (Single Random Length), DRL (Double Random Length), 20Ft (6Mtr), 40Ft (12Mtr), Cut Length
API 5L GR. B Pipe Pipe Ends	:	Plain, Bevel, Screwed, Threaded
API 5L GR. B Pipe Coating Finish Types	:	Bare, Oiled, Mill Varnish, Galvanized, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap End
API 5L GR. B Pipe Packing	:	Steel Bundle, Plastic Caps on both ends, Woven bag, Wooden Box or as per clients’ needs
API 5L GR. B Pipe Origin	:	Indian Origin, Japanese Origin, Korean Origin, European Origin, US Origin, Ukraine Origin, Russian Origin

API 5L X42 Steel Pipe Price List :-

API 5L GR. B Pipe Price	Origin	Price in INR (INR/Ton)	Price in USD(USD/Ton)
API 5L GR. B Pipe Price in India	Indian	Rs.80,000 - Rs.90,000	$1050 - $1200
API 5L GR. B Pipe Price in Korea	Korean	Rs.90,000 - Rs.100,000	$1200 - $1300
API 5L Steel Pipe Price in Japan	Japanese	Rs.105,000 - Rs.110,000	$1400 - $1500
API 5L Steel Pipe Price in Europe	European	Rs.110,000 - Rs.120,000	$1500 - $1600
API 5L Steel Pipe Price in USA	USA	Rs.110,000 - Rs.120,000	$1500 - $1600

API 5L GR. B Pipe Chemical Composition :-


Steel Grade	Mass fraction, % based on heat and product analyses a,g
	C	Mn	P	S	V	Nb	Ti
	max b	max b	max	max	max	max	max
Seamless Pipe
GR. B / L245	0.28	1.3	0.3	0.3	d	d	d
Welded Pipe
GR. B / L245	0.26	1.2	0.3	0.3	c,d	c,d	d

API 5L GR. B Pipe Chemical Composition :-

Steel Grade	Mass fraction, % based on heat and product analyses									Carbon Equiv a
	C	Si	Mn	P	S	V	Nb	Ti	Other	CE IIW	CE Pcm
	max b	max	max b	max	max	max	max	max	Other	max	max
Seamless and Welded Pipe
GR. BR / L245R	0.24	0.4	1.2	0.025	0.015	c	c	0.04	e,l	0.43	0.25
GR. BN / L245N	0.24	0.4	1.2	0.025	0.015	c	c	0.04	e,l	0.43	0.25
GR. BQ / L245Q	0.18	0.45	1.4	0.025	0.015	0.05	0.05	0.04	e,l	0.43	0.25
Welded Pipe
GR. BM / L245M	0.22	0.45	1.2	0.025	0.015	0.05	0.05	0.04	e,l	0.43	0.25

API 5L GR. B Pipe Mechanical Properties :-

Pipe Grade	Tensile Properties - Pipe Body of SMLS and Welded Pipes PSL 1			Seam of Welded Pipe
	Yield Strength a	Tensile Strength a	Elongation	Tensile Strength b
	R_t0,5 MPa (psi) Min	Rm MPa (psi) Min	(in 2in Af % min)	Rm MPa (psi) Min
GR. B / L245	245 (35,500)	415 (60,200)	c	415 (60,200)

API 5L GR. B Pipe Mechanical Properties :-

Pipe Grade	Tensile Properties - Pipe Body of SMLS and Welded Pipes PSL 2						Seam of Welded Pipe
	Yield Strength a		Tensile Strength a		Ratio a,c	Elongation (in 2in)	Tensile Strength d
	R_t0,5 MPa (psi)		Rm MPa (psi)		R_10,5IR_m	Af %	R_m MPa (psi)
	Minimum	Maximum	Minimum	Maximum	Maximum	Minimum	Minimum
GR. BN / L245N	245 (35,500)	450 (65,300)	415 (60,200)	655 (95,000)	0.93	f	415 (60,200)
GR. BQ / L245Q
GR. BM / L245M

API 5L GR. B Line Pipe Test :-

Flattening Test
Hydrostatic Test
Bend test
Ultrasonic Test
CVN impact test for PSL2 pipe (including pipe body tests, pipe weld and HAZ tests for SEAM Pipes)
DWT test for PSL2 welded pipe

API 5L GR. B Steel Pipe Certification and Traceability :-

API 5L GR. B Pipes will be supplied with a 3.1/3.2 certificate according to EN 10204, endorsed by recognized and independent inspection agency. Mill TC EN 10204 3.1/3.2, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, Destructive Test Report, Non Destructive Test Reports, , NABL Approved Lab, Chemical and Mechanical Reports.

API 5L GR. B Line Pipe Application :-

API 5L GR. B high yield carbon steel pipe is commonly known for transporting water, oil, and gas We can help supply all of the High Yield Seamless API 5L line pipe supplies that your company needs for use in a wide range of industries.
Some of the common industries we serve include:

Oil & Gas
Chemical
Infrastructure
Oil and Gas Pipeline

Natural Gas
Water
Fabrication
Water and Sewage Pipeline

Petroleum
Refineries
Construction
Mineral Slurry Pipeline
