API 5L SEAMLESS & WELDED LINE PIPE SUPPLIER
Multi Metals (India) specializes in API 5L PSL1 & PSL2 Pipes certified and tested in accordance with ISO 3183, ISO 15156, NACE MRO175 / 103, HIC, SWC, SSC, SSCC, SOUR SERVICE, H2 SERVICE, IMPACT, POST WELD HEAT TREATMENT (PWHT), IBR, HIGH YIELD, IPS-M-PI-190, IPS-M-PI-221 ETC.
We solicit contacts from reputed Pipe mills to represent them & stock their products for resale to EPC Companies / Promoting Companies.
We today stock nearly 8000MT of API 5L Line Pipes, that include critical grades B, X42, X46, X52, X56, X60, X65, X70, X80 in form of Seamless / Welded / SAW Pipes size ranging from 1/2" to 100" of different mills which can handle extreme temperatures, pressures and corrosive environment.
High Yield API 5L Seamless & Welded Carbon Steel Pipe Manufacturer
Stockist, Exporter of API 5L Seamless & Welded Line Pipe – PSL1 & PSL2
API 5L Grade B, X42, X46, X52, X56, X60, X65, X70, X80 FOR SALE AT BEST PRICE IN INDIA
Table of Contents :-
API 5L Standard Specification for Line Pipe :
The American Petroleum Institute specification API 5L addresses seamless and welded steel line pipe for pipeline transportation systems in the petroleum and natural gas industries. API 5L is suitable for conveying gas, water, and oil. API pipes are produced into seamless pipe and welded steel pipe with Spiral Submerged Arc Welding Pipe (SSAW), Longitudinal Seam Submerged Arc Welding Pipe (LSAW), Electric Resistance Welding (ERW)
- API 5L Line Pipes ranges in PSL1, PSL2, onshore/offshore, and sour service.
- PSL1 is for common use material delivery conditions R as Rolled.
- PSL2 is strict and higher than PSL1 on chemicals, mechanical properties and test requirements.
- PSL2 specified with suffix letter N, Q, M, eg API 5L X60Q/M/N (Where sour services is described as API 5L X60QS/MS)
Suffix Letter Means :
- R: As rolled
- N: Normalizing rolled, Normalized formed, Normalized
- Q: Quenched & Tempered
- M: Thermomechanical rolled or Thermomechanical formed
- S: Sour Service Use
View here differences between PSL1 and PSL2.
View API 5L Pipe Specification (46th Edition Updated on 2020)
SUPPLY RANGE :
|
API 5L Pipe Grade
|
: |
API 5L Gr. B, X42,
X46, X52, X56, X60, X65, X70, X80 (Q, M, N, QS, MS)
|
|
API 5L Pipe Product Specification Level
|
: |
PSL1, PSL2, NACE,
Sour Service, HIC, SSC, H2 Service
|
|
API 5L Pipe
Types
|
: |
Seamless and Welded in ERW, LSAW, DSAW, SSAW (HSAW)
.
|
|
API 5L Pipe OD
Range (Seamless)
|
: |
1/2” – 30” (21.3 mm
– 762 mm)
|
|
API 5L Pipe OD
Range (ERW)
|
: |
1/2” – 20” (21.3mm
– 508mm)
|
|
API 5L Pipe OD
Range (LSAW/DSAW)
|
: |
16” – 100” (406mm –
2500MM)
|
|
API 5L Pipe OD
Range (SSAW/HSAW)
|
: |
up to 100” (2500mm)
|
|
API 5L Pipe Wall
Thickness / Schedule
|
: |
SCH-20, SCH-40,
SCH-STD, SCH-XS, SCH-80, SCH-100, SCH-120, SCH-160, SCH-XXS, HEAVY THICKNESS
|
|
API 5L Pipe Pipe Length
|
: |
SRL (Single Random
Length), DRL (Double Random Length), 20Ft (6Mtr), 40Ft (12Mtr),
Cut Length
|
|
API 5L Pipe Pipe Ends
|
: |
Plain, Bevel,
Screwed, Threaded
|
|
API 5L Pipe Coating
Finish Types
|
: |
Bare, Oiled, Mill
Varnish, Galvanized, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating
and Tape Wrap End
|
|
API 5L Pipe
Packing
|
: |
Steel Bundle,
Plastic Caps on both ends, Woven bag, Wooden Box or as per clients’ needs
|
|
API 5L Pipe Origin
|
:
|
Indian Origin,
Japanese Origin, Korean Origin, European Origin, US Origin, Ukraine Origin,
Russian Origin
|
API 5L Steel Pipe Price List :
| API 5L Steel Pipe Price (X42-X80) | Origin | Price in INR(INR/Ton) | Price in USD(USD/Ton) |
|---|---|---|---|
| API 5L Steel Pipe Price in India | Indian | Rs.80,000 - Rs.125,000 | $1050 - $1700 |
| API 5L Steel Pipe Price in Korea | Korean | Rs.90,000 - Rs.145,000 | $1200 - $1900 |
| API 5L Steel Pipe Price in Japan | Japanese | Rs.105,000 - Rs.160,000 | $1400 - $2100 |
| API 5L Steel Pipe Price in Europe | European | Rs.110,000 - Rs.170,000 | $1500 - $2300 |
| API 5L Steel Pipe Price in USA | USA | Rs.110,000 - Rs.170,000 | $1500 - $2300 |
Typical process of Manufacturing :
Ingots, blooms, billets, coils or plates used for the manufacture of pipe shall be made by the following processes, basic oxygen, electric furnace or open hearth in combination with a ladle refining process. For PSL2, the steel shall be killed and melted according to a fine grain practice. Coil or plate used for PSL2 pipe shall not contain any repair welds.
|
Type of Pipe
|
PSL
1
|
PSL
2
|
|||
|
Grade A
|
Grade B
|
X42 to X70
|
B to X80
|
X80 to X100
|
|
|
SMLS
|
ü
|
ü
|
ü
|
ü
|
ü
|
|
LFW
|
ü
|
ü
|
ü
|
|
|
|
HFW
|
ü
|
ü
|
ü
|
ü
|
|
|
LW
|
|
|
ü
|
|
|
|
SAWL
|
ü
|
ü
|
ü
|
ü
|
ü
|
|
SAWH
|
ü
|
ü
|
ü
|
ü
|
ü
|
|
SMLS – Seamless, without weld
LFW – Low frequency welded pipe, <70 kHz
HFW – High frequency welded pipe, >70 kHz
SAWL – Submerge-arc welding longitudinal welded
SAWH - Submerge-arc welding helical welded
|
|||||
API 5L PSL-1 Pipe Chemical Composition :
| Steel Grade | Mass fraction, % based on heat and product analyses a,g | ||||||
| C | Mn | P | S | V | Nb | Ti | |
| max b | max b | max | max | max | max | max | |
| Seamless Pipe | |||||||
| B / L245 | 0.28 | 1.2 | 0.3 | 0.3 | c,d | c,d | d |
| X42 / L290 | 0.28 | 1.3 | 0.3 | 0.3 | d | d | d |
| X46 / L320 | 0.28 | 1.4 | 0.3 | 0.3 | d | d | d |
| X52 / L360 | 0.28 | 1.4 | 0.3 | 0.3 | d | d | d |
| X56 / L390 | 0.28 | 1.4 | 0.3 | 0.3 | d | d | d |
| X60 / L415 | 0.28 e | 1.40 e | 0.3 | 0.3 | f | f | f |
| X65 / L450 | 0.28 e | 1.40 e | 0.3 | 0.3 | f | f | f |
| X70 / L485 | 0.28 e | 1.40 e | 0.3 | 0.3 | f | f | f |
| Welded Pipe | |||||||
| B / L245 | 0.26 | 1.2 | 0.3 | 0.3 | c,d | c,d | d |
| X42 / L290 | 0.26 | 1.3 | 0.3 | 0.3 | d | d | d |
| X46 / L320 | 0.26 | 1.4 | 0.3 | 0.3 | d | d | d |
| X52 / L360 | 0.26 | 1.4 | 0.3 | 0.3 | d | d | d |
| X56 / L390 | 0.26 | 1.4 | 0.3 | 0.3 | d | d | d |
| X60 / L415 | 0.26 e | 1.40 e | 0.3 | 0.3 | f | f | f |
| X65 / L450 | 0.26 e | 1.45 e | 0.3 | 0.3 | f | f | f |
| X70 / L485 | 0.26e | 1.65 e | 0.3 | 0.3 | f | f | f |
API 5L PSL-2 PIPE CHEMICAL COMPOSITION :
| Steel Grade | Mass fraction, % based on heat and product analyses | Carbon Equiv a | |||||||||
| C | Si | Mn | P | S | V | Nb | Ti | Other | CE IIW | CE Pcm | |
| max b | max | max b | max | max | max | max | max | max | max | ||
| Seamless and Welded Pipe | |||||||||||
| BR / L245R | 0.24 | 0.4 | 1.2 | 0.025 | 0.015 | c | c | 0.04 | e,l | 0.43 | 0.25 |
| X42R / L290R | 0.24 | 0.4 | 1.2 | 0.025 | 0.015 | 0.06 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| BN / L245N | 0.24 | 0.4 | 1.2 | 0.025 | 0.015 | c | c | 0.04 | e,l | 0.43 | 0.25 |
| X42N / L290N | 0.24 | 0.4 | 1.2 | 0.025 | 0.015 | 0.06 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| X46N / L320N | 0.24 | 0.4 | 1.4 | 0.025 | 0.015 | 0.07 | 0.05 | 0.04 | d,e,l | 0.43 | 0.25 |
| X52N / L360N | 0.24 | 0.45 | 1.4 | 0.025 | 0.015 | 0.1 | 0.05 | 0.04 | d,e,l | 0.43 | 0.25 |
| X56N / L390N | 0.24 | 0.45 | 1.4 | 0.025 | 0.015 | 0.10f | 0.05 | 0.04 | d,e,l | 0.43 | 0.25 |
| X60N / L415N | 0.24f | 0.45f | 1.40f | 0.025 | 0.015 | 0.10f | 0.05f | 0.04f | g,h,l | As agreed | |
| BQ / L245Q | 0.18 | 0.45 | 1.4 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| X42Q / L290Q | 0.18 | 0.45 | 1.4 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| X46Q / L320Q | 0.18 | 0.45 | 1.4 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| X52Q / L360Q | 0.18 | 0.45 | 1.5 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| X56Q / L390Q | 0.18 | 0.45f | 1.5 | 0.025 | 0.015 | 0.07 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| X60Q / L415Q | 0.18f | 0.45f | 1.70f | 0.025 | 0.015 | g | g | g | h,l | 0.43 | 0.25 |
| X65Q / L450Q | 0.18f | 0.45f | 1.70f | 0.025 | 0.015 | g | g | g | h,l | 0.43 | 0.25 |
| X70Q / L485Q | 0.18f | 0.45f | 1.80f | 0.025 | 0.015 | g | g | g | h,l | 0.43 | 0.25 |
| X80Q / L555Q | 0.18f | 0.45f | 1.90f | 0.025 | 0.015 | g | g | g | i,j | As agreed | |
| Welded Pipe | |||||||||||
| BM / L245M | 0.22 | 0.45 | 1.2 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| X42M / L290M | 0.22 | 0.45 | 1.3 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| X46M / L320M | 0.22 | 0.45 | 1.3 | 0.025 | 0.015 | 0.05 | 0.05 | 0.04 | e,l | 0.43 | 0.25 |
| X52M / L360M | 0.22 | 0.45 | 1.4 | 0.025 | 0.015 | d | d | d | e,l | 0.43 | 0.25 |
| X56M / L390M | 0.22 | 0.45f | 1.4 | 0.025 | 0.015 | d | d | d | e,l | 0.43 | 0.25 |
| X60M / L415M | 0.12f | 0.45f | 1.60f | 0.025 | 0.015 | g | g | g | h,l | 0.43 | 0.25 |
| X65M / L450M | 0.12f | 0.45f | 1.60f | 0.025 | 0.015 | g | g | g | h,l | 0.43 | 0.25 |
| X70M / L485M | 0.12f | 0.45f | 1.70f | 0.025 | 0.015 | g | g | g | h,l | 0.43 | 0.25 |
| X80M / L555M | 0.12f | 0.45f | 1.85f | 0.025 | 0.015 | g | g | g | i,j | 0.43f | 0.25 |
API 5L PSL-1 Pipe Mechanical Properties :
| Pipe Grade | Tensile Properties - Pipe Body of SMLS and Welded Pipes PSL 1 | Seam of Welded Pipe | ||
| Yield Strength a | Tensile Strength a | Elongation | Tensile Strength b | |
| Rt0,5 MPa (psi) Min | Rm MPa (psi) Min | (in 2in Af % min) | Rm MPa (psi) Min | |
| B / L245 | 245 (35,500) | 415 (60,200) | c | 415 (60,200) |
| X42 / L290 | 290 (42,100) | 415 (60,200) | c | 415 (60,200) |
| X46 / L320 | 320 (46,400) | 435 (63,100) | c | 435 (63,100) |
| X52 / L360 | 360 (52,200) | 460 (66,700) | c | 460 (66,700) |
| X56 / L390 | 390 (56,600) | 490 (71,100) | c | 490 (71,100) |
| X60 / L415 | 415 (60,200) | 520 (75,400) | c | 520 (75,400) |
| X65 / L450 | 450 (65,300) | 535 (77,500) | c | 535 (77,500) |
| X70 / L485 | 485 (70,300) | 570 (82,700) | c | 570 (82,700) |
API 5L PSL-2 Pipe Mechanical Properties :
| Pipe Grade | Tensile Properties - Pipe Body of SMLS and Welded Pipes PSL 2 | Seam of Welded Pipe | |||||
| Yield Strength a | Tensile Strength a | Ratio a,c | Elongation (in 2in) | Tensile Strength d | |||
| Rt0,5 MPa (psi) | Rm MPa (psi) | R10,5IRm | Af % | Rm MPa (psi) | |||
| Minimum | Maximum | Minimum | Maximum | Maximum | Minimum | Minimum | |
| BR, BN,BQ,BM | 245 (35,500) | 450 (65,300) | 415 (60,200) | 655 (95,000) | 0.93 | f | 415 (60,200) |
| X42,X42R,X2Q,X42M | 290 (42,100) | 495 (71,800) | 415 (60,200) | 655 (95,000) | 0.93 | f | 415 (60,200) |
| X46N,X46Q,X46M | 320 (46,400) | 525 (76,100) | 435 (63,100) | 655 (95,000) | 0.93 | f | 435 (63,100) |
| X52N,X52Q,X52M | 360 (52,200) | 530 (76,900) | 460 (66,700) | 760 (110,200) | 0.93 | f | 460 (66,700) |
| X56N,X56Q,X56M | 390 (56,600) | 545 (79,000) | 490 (71,100) | 760 (110,200) | 0.93 | f | 490 (71,100) |
| X60N,X60Q,S60M | 415 (60,200) | 585 (81,900) | 520 (75,400) | 760 (110,200) | 0.93 | f | 520 (75,400) |
| X65Q,X65M | 450 (65,300) | 600 (87,000) | 535 (77,500) | 760 (110,200) | 0.93 | f | 535 (77,500) |
| X70Q,X70M | 485 (70,300) | 635 (92,100) | 570 (82,700) | 760 (110,200) | 0.93 | f | 570 (82,700) |
| X80Q,X80M | 555 (80,500) | 705 (102,300) | 625 (90,600) | 825 (119,700) | 0.93 | f | 625 (90,600) |
API 5L Line Pipe Test :
- Flattening Test
- Hydrostatic Test
- Bend test
- Ultrasonic Test
- DWT test for PSL2 welded pipe
API 5LSteel Pipe Certification and Traceability :
API 5L Pipes will be supplied with a 3.1/3.2 certificate according to EN 10204, endorsed by recognized and independent inspection agency. Mill TC EN 10204 3.1/3.2, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, Destructive Test Report, Non Destructive Test Reports, NABL Approved Lab, Chemical and Mechanical Reports.
API 5L Line Pipe Application :
-
Oil & Gas
-
Chemical
-
Infrastructure
-
Oil and Gas Pipeline
-
Natural Gas
-
Water
-
Fabrication
-
Water and Sewage Pipeline
-
Petroleum
-
Refineries
-
Construction
-
Mineral Slurry Pipeline
