ASTM A672 CARBON STEEL EFW PIPES SUPPLIER
Multi Metals (India) is India's largest exporter of ASTM A672 EFW Pipes in a variety of sizes to meet the project piping requirements for applications in water, petroleum, oil & gas and other industries. We solicit contacts from reputed Pipe mills to represent them & stock their products for resale to EPC Companies / Promoting Companies.
We today stock nearly 8000MT of Carbon Steel ASTM A672EFW Pipes, that include critical grades A672 B60, A672 B65, A672 B70, A672 C60, A672 C65, A672 C70 in Class 12,22, 32 size ranging from 16" to 100" of different mills which can handle extreme temperatures, pressures and corrosive environment. The various grades and class designations indicates the testing methods required for a given application.
A672 Pipe Supplier | A672 B60 / B65 / B70 / C60 / C65 / C70 CLASS 12, 22, 32
ASME SA672 EFW Pipe Manufacturer in India
ASTM A672 Welded Pipes at Best Price - A672 B60 | A672 B65 | A672 B70 | A672 C60 | A672 C65 | A672 C70
Table of Contents :-
ASTM A672 EFW Pipe specification :-
ASTM A672 Pipe is Standard Specification for Electric-Fusion-Welded Steel Pipe for High-Pressure Service at Moderate Temperatures. This specification covers steel pipe 16 inches in outside diameter or larger that is electric fusion welded (EFW) with filler metal added, fabricated from pressure vessel quality plate and suitable for high-pressure service at moderate temperatures. Several grades designate the type of plate used; classes designate the type of heat treatment performed during the manufacture of the pipe, whether the weld is radiographically examined, and if the pipe has been pressure tested.
ASTM A672 EFW Pipe Supply Range :-
|
A672 EFW Pipe
Specification |
: |
ASTM A672 / ASME
SA672 |
|
A672 EFW Pipe Grade |
: |
ASTM A672 Grade
B60/B65/B70/C60/C65/C70 |
|
A672 EFW Pipe Types |
: |
EFW (ELECTRIC
FUSION WELDED PIPES) |
|
A672 EFW Pipe Class
Designation |
: |
CLASS 10, 11, 12,
13, 20, 21, 22, 23, 30, 31, 32, 33, 40, 41, 42 |
|
A672 EFW Pipe OD
Range |
: |
16" NB To
100" NB (Nominal Bore Size) |
|
A672 EFW Pipe Wall
Thickness / Schedule |
: |
SCH-20, SCH-40,
SCH-STD, SCH-XS, SCH-80, SCH-100, SCH-120, SCH-160, SCH-XXS, HEAVY THICKNESS |
|
A672 EFW Pipe Length |
: |
SRL (Single Random
Length), DRL (Double Random Length), 20Ft (6Mtr), 40Ft (12Mtr),
Cut Length |
|
A672 EFW Pipe Ends |
: |
Plain, Bevel,
Screwed, Threaded |
|
A672 EFW Pipe
Coating Finish Types |
: |
Bare, Oiled, Mill
Varnish, Galvanized, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating
and Tape Wrap End |
|
A672 EFW Pipe
Packing |
: |
Steel Bundle,
Plastic Caps on both ends, Woven bag, Wooden Box or as per clients’ needs |
|
A672 EFW Pipe
Origin |
: |
Indian Origin,
Japanese Origin, Korean Origin, European Origin, US Origin, Ukraine Origin,
Russian Origin |
|
A672 EFW Pipe Test
Certificates |
: |
Manufacturer Test
Certificate As Per EN10204 3.1, 3.2 / Lab Report from NABL Approved Lab. /
Third Party Inspection |
ASTM A672 EFW PIPE Price List :-
| ASTM A672 EFW Pipe Price (C60/C65/C70) | Origin | Price in INR(INR/Ton) | Price in USD(USD/Ton) |
| ASTM A672 EFW Pipe Price in India | Indian | Rs.80,000 - Rs.95,000 | $1000 - $1200 |
| ASTM A672 EFW Pipe Price in Korea | Korean | Rs.85,000 - Rs.100,000 | $1050 - $1250 |
| ASTM A672 EFW Pipe Price in Japan | Japanese | Rs.90,000 - Rs.110,000 | $1100 - $1350 |
| ASTM A672 EFW Pipe Price in Europe | European | Rs.105,000 - Rs.125,000 | $1300 - $1550 |
| ASTM A672 EFW Pipe Price in USA | USA | Rs.105,000 - Rs.125,000 | $1300 - $1550 |
ASTM A672 EFW PIPE Chemical Composition :-
|
Specification |
Steel Grade |
Chemical Composition % |
|||||
|
C (max) |
Si |
Mn (max) |
P (max) |
S (max) |
Ti (max) |
||
|
Pipes for pressure service ASTM A672 |
-/B55 |
-/0.20 |
0.13~0.45 |
0.98 |
0.035 |
0.035 |
- |
|
B60 |
0.24 |
0.13~0.45 |
0.98 |
0.035 |
0.035 |
- |
|
|
B65 |
0.28 |
0.13~0.45 |
0.98 |
0.035 |
0.035 |
- |
|
|
B70 |
0.31 |
0.13~0.45 |
1.30 |
0.035 |
0.035 |
- |
|
|
-/C55 |
-/0.18 |
0.13~0.45 |
0.55~0.98 |
0.035 |
0.035 |
- |
|
|
C60 |
0.21 |
0.13~0.45 |
0.55~0.98 |
0.035 |
0.035 |
- |
|
|
C65 |
0.24 |
0.13~0.45 |
0.79~1.30 |
0.035 |
0.035 |
- |
|
|
C70 |
0.27 |
0.13~0.45 |
0.79~1.30 |
0.035 |
0.035 |
- |
|
ASTM A672 EFW PIPE Mechanical Properties :-
|
Products |
Steel Grade |
Base Metal Mechanical Composition |
Welding Point Tensile Strength (N/mm2) |
Remarks |
|||
|
Yield point (N/mm2) (min) |
Tensile Strength (N/mm2) |
Test Pieces |
Elongation (%) (min) |
||||
|
Pipes for pressure service ASTM A672 |
-/B55 |
-/205 |
-/380~515 |
|
-/27 |
-/380~515 |
|
|
B60 |
220 |
415~550 |
25 |
415~550 |
|||
|
B65 |
240 |
450~585 |
23 |
450~585 |
|||
|
B70 |
260 |
485~620 |
21 |
485~620 |
|||
|
-/C55 |
-/205 |
-/380~515 |
-/27 |
-/380~515 |
|||
|
C60 |
220 |
415~550 |
25 |
415~550 |
|||
|
C65 |
240 |
450~585 |
23 |
450~585 |
|||
|
C70 |
260 |
485~620 |
21 |
485~620 |
|||
ASTM A672 EFW Pipe - Plate Specification :-
|
Pipe Grade |
Type of Steel |
ASTM Plate Specification |
|
|
No. |
Grade / Class / Type |
||
|
ASTM A672 Grade B55 |
plain carbon, killed |
A515/A515M |
Gr 55 |
|
ASTM A672 Grade C55 |
plain carbon, killed, fine grain |
A516/A516M |
Gr 55 |
|
ASTM A672 Grade B60 |
plain carbon, killed |
A515/A515M |
Gr 60 |
|
ASTM A672 Grade C60 |
plain carbon, killed, fine grain |
A516/A516M |
Gr 60 |
|
ASTM A672 Grade B65 |
plain carbon, killed |
A515/A515M |
Gr 65 |
|
ASTM A672 Grade C65 |
plain carbon, killed, fine grain |
A516/A516M |
Gr 65 |
|
ASTM A672 Grade B70 |
plain carbon, killed |
A515/A515M |
Gr 70 |
|
ASTM A672 Grade C70 |
plain carbon, killed, fine grain |
A516/A516M |
Gr 70 |
ASTM A672 EFW PIPE Heat Treatment Requirements :-
|
Pipe Grade |
ASTM Specification and Grade |
Post-Weld Heat-Treatment |
Normalizing |
Quenching |
Tempering Temperature min, °F(°C) |
|
ASTM A672 |
|||||
|
B 55 |
A 515/A 515M (55) |
1100-1250 (590-680) |
1750 (950) |
- |
- |
|
B 60 |
A 515/A 515M (60) |
1100-1250 (590-680) |
1750 (950) |
- |
- |
|
B 65 |
A 515/A 515M (65) |
1100-1250 (590-680) |
1750 (950) |
- |
- |
|
B 70 |
A 515/A 515M (70) |
1100-1250 (590-680) |
1750 (950) |
- |
- |
|
C 55 |
A 516/A 516M (55) |
1100-1250 (590-680) |
1750 (925) |
1650 (900) |
1200 (650) |
|
C 60 |
A 516/A 516M (60) |
1100-1250 (590-680) |
1750 (925) |
1650 (900) |
1200 (650) |
|
C 65 |
A 516/A 516M (65) |
1100-1250 (590-680) |
1750 (925) |
1650 (900) |
1200 (650) |
|
C 70 |
A 516/A 516M (70) |
1100-1250 (590-680) |
1750 (925) |
1650 (900) |
1200 (650) |
ASTM A672 EFW Pipe Certification and Traceability :-
ASTM A672 EFW Pipes will be supplied with a 3.1/3.2 certificate according to EN 10204, endorsed by recognized and independent inspection agency. Mill TC EN 10204 3.1/3.2, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, Destructive Test Report, Non Destructive Test Reports, , NABL Approved Lab, Chemical and Mechanical Reports
ASTM A672 EFW Pipe Application :-
ASTM A672 EFW Pipe is commonly known for High-Pressure Service at Moderate Temperatures Service requirements.
We can help supply all of ASTM A672 EFW Pipe supplies that your company needs for use in a wide range of industries.
Some of the common industries we serve include:
-
Oil & Gas
-
Chemical
-
Infrastructure
-
Oil and Gas Pipeline
-
Natural Gas
-
Water
-
Fabrication
-
Water and Sewage Pipeline
-
Petroleum
-
Refineries
-
Construction
-
Mineral Slurry Pipeline
