ASTM A335 CHROME MOLY ALLOY STEEL
SEAMLESS PIPE SUPPLIER
As a chrome moly pipe supplier, Multi Metals (India) supplies seamless A335 chrome pipe for a variety of projects and applications for High Temperature Service. Often referred to as “P-Grade” material, Grades P-11, P-22 - P-91 & P-92 are prevalent grades for the power industry, while P-5 & P-9 are the grades utilized in major refinery processing.
We today stock nearly 5000MT of Chrome-Moly Alloy Steel ASTM A335 Steel Pipes, in seamless size ranging from 1/2" to 30" which is renowned for its tensile strength, corrosion resistance, high-temperature strength and cost-effectiveness. It is used in a wide variety of applications because of its versatile strength. All of these characteristics make chrome moly pipe an effective standard, especially in the power generation and petro-chemical industries. We solicit contacts from reputed Pipe mills to represent them & stock their products for resale to EPC Companies / Promoting Companies.
ASME SA335 Grade P5 / P9 / P11 / P12 / P22 / P91 Seamless Pipe Supplier
ALLOY STEEL A335 Gr. P5 / P9 / P11 / P12 / P22 / P91 Pipe Manufacturer in India
ASTM/ASME A335 Seamless Pipes at Best Price in India
Table of Contents :-
ASTM A 335 Steel Pipe Specification :-
ASTM A335 (ASME SA335) is the standard specification for seamless ferritic alloy steel pipe for high-temperature service
This specification covers nominal wall and minimum wall seamless chrome moly seamless pipes for the power generation and petrochemical industries. ASTM A335 Seamless Steel Pipe ordered to this specification shall be suitable for fusion welding, bending, flanging (vanstoning), and similar forming operations. With chrome and moly element added, ASTM A335 offers good tensile strength, fine resistance to high temperature and corrosion.
It covers steel grades from P1 to P5, P9, P11, P22, P91. Grades P11/P22 and P91/92 are commonly used in power stations, while A335 grade P5 and P9 are mostly used for application in the petrochemical industry.
Pipe may be either hot finished or cold drawn with the finishing heat treatment
SUPPLY RANGE :-
| A335 Steel Pipe Specification | : | ASTM A335 / ASME SA335 |
| A335 Steel Pipe Grade | : | ASTM A335 Grade P5 / P9 / P11 / P12 / P22 / P91 / P92 |
| A335 Steel Pipe Types | : | Seamless / ERW / Welded / Fabricated / CDW |
| A335 Steel Pipe OD Range | : | 1/2" NB To 30" NB (Nominal Bore Size) |
| A335 Steel Pipe Wall Thickness / Schedule | : | SCH-20, SCH-40, SCH-STD, SCH-XS, SCH-80, SCH-100, SCH-120, SCH-160, SCH-XXS, HEAVY THICKNESS |
| A335 Steel Pipe Length | : | SRL (Single Random Length), DRL (Double Random Length), 20Ft (6Mtr), 40Ft (12Mtr), Cut Length |
| A335 Steel Pipe Ends | : | Plain, Bevel, Screwed, Threaded |
| A335 Steel Pipe Additional Testing | : | NACE MR0175, , HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| A335 Steel Pipe Coating Finish Types | : | Bare, Oiled, Mill Varnish, Galvanized, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap End |
| A335 Steel Pipe Packing | : | Steel Bundle, Plastic Caps on both ends, Woven bag, Wooden Box or as per clients’ needs |
| A335 Steel Pipe Origin | : | Indian Origin, Japanese Origin, Korean Origin, European Origin, US Origin, Ukraine Origin, Russian Origin |
| A335 Steel Pipe Test Certificates | : | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Lab Report from NABL Approved Lab. / Third Party Inspection |
ASTM A335 Steel Pipe Price List :-
| ASTM A335 Steel Pipe Price (Grade.P5/P9/P11/P22/P91) | Origin | A335 P5 Pipe | A335 P9 Pipe | A335 P11 Pipe | A335 P22 Pipe | A335 P91 Pipe |
| Price (USD/Ton) | Price (USD/Ton) | Price (USD/Ton) | Price (USD/Ton) | Price (USD/Ton) | ||
| ASTM A335 Steel Pipe Price in India | Indian | $3100 - $3850 | $3700 - $4350 | $1700 - $1900 | $1800 - $2000 | $3900 - $4750 |
| ASTM A335 Steel Pipe Price in Korea | Korean | $3500 - $4200 | $4200 - $4850 | $1900 - $2150 | $2050 - $2300 | $4650 - $5450 |
| ASTM A335 Steel Pipe Price in Japan | Japanese | $3900 - $4650 | $4550 - $5200 | $2200 - $2450 | $2350 - $2650 | $5100 - $5800 |
| ASTM A335 Steel Pipe Price in Europe | European | $4200 - $4900 | $4950 - $5550 | $2400 - $2700 | $2550 - $2900 | $5550 - $6250 |
| ASTM A335 Steel Pipe Price in USA | USA | $4200 - $4900 | $4950 - $5550 | $2400 - $2700 | $2550 - $2900 | $5550 - $6250 |
ASTM A335 STEEL PIPE Chemical Composition :-
| ASTM A335 Grade | UNS | Mass fraction, % based on heat and product analyses | ||||||
| C | Mn | P | S | Si | Cr | Mo | ||
| P5 | K41545 | 0.15 max | 0.30 – 0.60 | 0.025 max | 0.025 max | 0.50 max | 4.00 – 6.00 | 0.45 – 0.65 |
| P9 | S50400 | 0.15 max | 0.30 – 0.60 | 0.025 max | 0.025 max | 0.25 – 1.00 | 8.00 – 10.00 | 0.90 – 1.10 |
| P11 | K11597 | 0.05 – 0.15 | 0.30 – 0.60 | 0.025 max | 0.025 max | 0.50 – 1.00 | 1.00 – 1.50 | 0.44 – 0.65 |
| P22 | K21590 | 0.05 – 0.15 | 0.30 – 0.60 | 0.025 max | 0.025 max | 0.50 max | 1.90 – 2.60 | 0.87 – 1.13 |
| P91 | K91560 | 0.08 - 0.12 | 0.30 – 0.60 | 0.020 max | 0.010 max | 0.20 -0.50 | 8.00 – 9.50 | 0.85 – 1.05 |
| P91 shall also include | V: 0.18–0.25; N: 0.030–0.070, Ni: 0.40 max; Al: 0.04 max; Cb: 0.06–0.10 | |||||||
ASTM A335 STEEL PIPE Mechanical Properties :-
| ASTM A335 Grade | Tensile Strength, min., | Yield Strength, min., | ||
| ksi | MPa | ksi | MPa | |
| P5 | 60 | 415 | 30 | 205 |
| P9 | 60 | 415 | 30 | 205 |
| P11 | 60 | 415 | 30 | 205 |
| P22 | 60 | 415 | 30 | 205 |
| P91 | 85 | 585 | 60 | 415 |
ASTM A335 Steel Pipe Elongation Requirements :-
| Calculated Minimum Elongation Values | ||||
| Elongation in 2 in. or 50 mm, min % | ||||
| Wall Thickness | P5, P9, P11, P22 | P91 (type 1 &2) | ||
| in. | mm | Longitudinal | Transverse | Longitudinal |
| 5/16 (0.312) | 8 | 30 | 20 | 20 |
| 9/32 (0.281) | 7.2 | 28 | 19 | 19 |
| 1/4 (0.250) | 6.4 | 27 | 18 | 18 |
| 7/32 (0.219) | 5.6 | 26 | 17 | |
| 3/16 (0.188) | 4.8 | 24 | 16 | |
| 5/32 (0.156) | 4 | 22 | 15 | |
| 7/8 (0.125) | 3.2 | 21 | 14 | |
| 3/32 (0.094) | 2.4 | 20 | 13 | |
| 1/18 (0.062) | 1.6 | 18 | 12 | |
ASTM A335 Steel Pipe Heat Treatment Requirements :-
ASTM A335 steel pipe may be either hot finished or cold drawn with the finishing heat treatment noted below.
| ASTM A335 Grade | Heat Treatment Type | Normalizing Temperature Range °F[°C] |
Subcritical Annealing or Tempering Temperature Range °F[°C] |
| P5 (b,c) | Full or Isothermal Anneal | ||
| Normalize and Temper | - | 1250 [675] | |
| Subcritical Anneal (P5c only) | - | 1325 - 1375 [715 - 745] | |
| P9 | Full or Isothermal Anneal | ||
| Normalize and Temper | - | 1250 [675] | |
| P11 | Full or Isothermal Anneal | ||
| Normalize and Temper | - | 1200 [650] | |
| P22 | Full or Isothermal Anneal | ||
| Normalize and Temper | - | 1250 [675] | |
| P91 (type 1 and 2) | Normalize and Temper | 1900-1975 [1040 - 1080] | 1350-1470 [730 - 800] |
| Quench and Temper | 1900-1975 [1040 - 1080] | 1350-1470 [730 - 800] |
ASTM A335 Steel Pipe Certification and Traceability :-
ASTM A335 Pipes will be supplied with a 3.1/3.2 certificate according to EN 10204, endorsed by recognized and independent inspection agency. Mill TC EN 10204 3.1/3.2, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, Destructive Test Report, Non Destructive Test Reports, , NABL Approved Lab, Chemical and Mechanical Reports.
ASTM A335 Steel Pipe Application :-
Alloy Steel Pipe are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of Alloy Steel ASTM A335 Pipes for High-Temperature Service through a worldwide network of stock-keeping branches. These Pipes & Tubes is use in various industries like :
-
Power
-
Petroleum
-
Infrastructure
-
Boiler parts
-
Oil & Gas
-
Chemical
-
Fabrication
-
High pressure boiler
-
Natural Gas
-
Refineries
-
Construction
-
High temperature Resistant
